Descriptions:
This machine is applicable to pharmaceutical,food-industry and chemical industries.It can count,Full into bottles tablets(coated/span>capsules or not-coated) automatically and can also connected with the next Produce in production.
It is beautifully shaped,its construction is new and original.It is easily adjusted and applicable to productions of multiple specifications,it is an ideal packing equipment.
Features:
A .Transducer is adopted to regulate the running speed of the mainframe so as to match with various types of
Containers.
B.There is detection equipment that would not allow filling without bottles.
C.Transmission is operated within a box structure,which has a good effect of anti-dust and easy to be
lubricated.
D.Counting plate is specially designed of a swinging structure that gives off little noise and is also easy to
regulation.
E .According to GMP standard,there is a dust-collector.
Technical parameters:
Model |
PBS-100A |
PBS-100B |
Medicine Range |
Tablets: 3mm-30mm or made to need Capsules: 000#-5# |
Tablets: 3mm-50mm or made to need Capsules: 000#-5# |
Output capacity |
10-120bottles/min |
|
Counting plate size |
φ476mm |
φ593mm |
Frequency of vibration |
0-1400t.p.m |
|
Amplitude of vibration |
0-1.6mm |
|
Power |
1.1KW |
|
Voltage |
220v/380v,50hz/60hz,1/3 phase or made to need |
|
Overall dimension |
2230*1150*1800mm |
|
Weight |
470KG |
490kg |
Filling quantity/bottle |
1-150pcs/bottle for 10mm tablets 1-100pcs/bottle for 0# capsules |
1-240pcs for 10mm tablets 1-150pcs for 0# capsules |
